Product model
PJ-B551P-7
Screen description
55 inch ultra narrow side LED screen
Appearance size
Wide * high * Deep (mm)
1215.3*686.1*118
Visual area
Width * height (mm)
1209.6*680.4
Resolution ratio
1920*1080
On the ratio of
1500:1
Brightness
800cd/ square meters
Splicing gap
Less than 5.7mm
Overall power consumption
300W
Corresponding time
8ms
Color color
16.7M
Visual angle
178 degree /178 degree (H/V)
Screen life
>50000 hours
Panel driver
10-bit
Back light
WCG-CCFL backlight
Input port
HDMI, DVI, VGA, DVI, VGA, CVBS*4,
Image rotation
Support 90 degrees, 180 degrees, 270 degrees, 360 degrees rotation
input voltage
AC100V-240V
Menu language
Chinese and English (optional)
Video standard
PAL/NTSC automatic identification
Mosaic combination
Any M * any column (2 N = M, N = 15)
control mode
RS232 (physical interface: RJ45-8), remote control
Control loop
2 way RS232; physical interface: RJ45-8
Installation method
VESA standard mounting holes, wall mounted
Temperature / humidity
0 degrees C -60 C /10%-90%
Quality characteristics
Automatically adjust backlight brightness and
Multi angle rotation, easy to achieve special shaped stitching
3D digital noise reduction
HD high resolution, line scan, and software with black color
